Ruijie RG-ES207GS-PI-OD 7-Port Gigabit Outdoor Cloud Managed PoE+ Switch 4xPoE+ 2xSFP PoE-In/12V DC IP65

Overview

The Ruijie RG-ES207GS-PI-OD is an outdoor Gigabit switch from Ruijie’s Reyee Smart CCTV range, designed for camera points in car parks, parks, along highways and on large sites. It mounts on a wall or pole next to the cameras, and Ruijie describes it as an all-in-one outdoor switch that combines four devices into one.

It has five Gigabit RJ45 ports: ports 1–4 deliver PoE/PoE+ (IEEE 802.3af/at) to the cameras, and port 5 is the PoE-in uplink, accepting PoE, PoE+ or PoE++ (IEEE 802.3bt). One cable from the main PoE switch can therefore carry both the network and the power for the outdoor switch and its cameras — no separate mains supply at the pole. The PoE budget follows the input: 60 W from a 90 W PoE++ source, 40 W from 60 W PoE++, 19 W from 30 W PoE+ and 6 W from 15.4 W PoE. The switch can also run from a 12 V DC supply (0.5 A rated), in which case its PoE outputs are not powered.

Two 1G SFP ports take fibre modules for long uplinks and support ERPS ring protection. The fanless, fully dustproof and jet-water-resistant IP65 plastic housing is rated −30°C to +65°C, with ±8 kV common-mode surge protection on the camera ports. Manage it free through Ruijie Cloud, the Reyee app or the built-in eWeb interface: camera detection, PoE watchdog, cable test, uninterrupted PoE through a warm restart, 802.1Q VLANs (up to 32), storm control, DHCP snooping and port mirroring. Netview CCTV in Leicester is a UK Ruijie reseller — call 0116 3800 838 for trade pricing.

Key Features

• 4× Gigabit PoE/PoE+ ports (IEEE 802.3af/at) for IP cameras
• PoE++ (802.3bt) or 12 V DC input — up to 60 W PoE budget from a 90 W PoE++ source
• 2× 1G SFP ports for fibre uplinks and ERPS ring redundancy
• IP65 outdoor housing, −30°C to +65°C, fanless, wall or pole mounting
• ±8 kV surge protection on PoE ports 1–4
• Ruijie Cloud / Reyee app / eWeb management with camera detection, PoE watchdog and cable test
• Uninterrupted PoE through a warm restart
• 14 Gbps switching capacity, 10.42 Mpps forwarding, 3-year warranty

PoE Budget by Power Input

Source: Ruijie RG-ES207GS-PI-OD datasheet (2026-09-28).

Typical Applications

• Pole-mounted CCTV in car parks, parks and along roads — Ruijie’s own target sites
• Remote camera clusters powered by a single PoE++ cable from the main switch
• Fibre-linked camera points and ERPS ring networks on large sites via the two SFP ports
• Sites with a 12 V DC supply — the switch runs on DC (cameras then need their own power)
• Trade installs — Netview CCTV Leicester supplies the Ruijie / Reyee range

Compatible Devices

• IP cameras with PoE / PoE+ (IEEE 802.3af/at) — Hikvision, HiLook and other standards-based cameras
• An upstream PoE++ (IEEE 802.3bt) switch port or injector to power the switch and its cameras over one cable
• 1G SFP modules — e.g. Ruijie RG-NIS-GE-SFP industrial or RG-MINI-GBIC modules for fibre uplinks
• Ruijie Cloud and the Reyee app (free) for remote management

What’s in the Box

• 1 × Ruijie RG-ES207GS-PI-OD outdoor switch
• 1 × mounting bracket
• 2 × hose clamps (pole mounting)
• 4 × ST4.2 × 19 mm screws and 4 × expansion anchors
• 1 × terminal block (DC input)
• 1 × user manual and warranty card
