SFX 305m Cat5e Premium UTP Cable Solid Copper PVC Grey
Secure-Flex SFX/C5-UTP-PVC-GRY-305 Cat5e Cable
305m SFX Cat5e Premium UTP PVC Solid Copper GREY
Solid copper Cat 5e U/UTP PVC jacket for use in indoor applications. Cat 5e U/UTP cable is designed and tested to achieve Gigabit Ethernet (1000 Base-T). Polyvinyl chloride plastic has excellent aging properties and will usually exceed a 25-30 year service life. Capable of 100mbps transfer speed or 100mhz frequency at a maximum distance of 90 meters
Key Features
- 4 x 24 AWG twisted pairs
- Full Solid Copper
- PVC jacket for internal use.
- 305m easy pull boxes
- Highly flexlibe cable
- Metre marking on the cable
- Delta EC verified
- HDBASE-T approved
- Data and CCTV transmission up to 100Mb/s
- Excellent performance exceeding ANSI/TIA Cat5e specifications
U/UTP : Unscreened overall, unscreened twisted pairs (often also called UTP)
Netview CCTV are an official wholesaler and supplier of SFX cables with direct access to great deals on the whole range of SFX communication cables. You can buy SFX cables online at netviewcctv.co.uk or collect from our warehouse in Leicester.
SFX cables product range includes
- Coax cables for TV, CCTV and satellite
- Category data cables
- FireAjax Fire Alarm vs Intruder Alarm: UK Compliance for Combined Systems alarm cable
- Intruder alarm cable
- Belden equivalent cables
- Audio cables
- Multi-core and screened cables
- Telephone cables
- Power cables
| Conductor | Bare Copper |
|---|---|
| Conductor Diameter (mm) | 0.47 ±0.01, 0.47 ±0.02 |
| Insulation | HDPE |
| Insulation Thickness (mm) | 0.18 |
| Insulation Colour | Blue/White/Blue;Orange/White/Orange;Green/White/Green;Brown/White/Brown |
| Insulation Thickness 2 (mm) | 0.88 ±0.08 |
| Nylon Rip-Cord | White 210D |
| Jacket | PVC |
| Jacket Colour | Grey RAL 7004 |
| Jacket Thickness (mm) | 0.49 ±0.03 |
| Overall Diameter (mm) | 4.80 ±0.03 |
| Overall Sheath | PVC |
| Overall Colour | Grey |
| Standards | ISO/IEC 11801, ANSI/TIA 568-C.2, CE2014/30/EU, LVD 2014/35/EU,RoHS2 2011/65/EU |
| CPR | Eca |
| Application | Internal Data and CCTV transmission up to 100Mb/s |
| EAN | 5056631502197 |
| AWG | 24 |
| Impedance (1-100MHz) | 100O ±15O |
| Drain Wire | N |
| Weight | 9.3 |
| Flame Propagation Standard | Eca |
