HiLook IPC-C340HA-D/W(2.8mm)(W) 4MP Indoor Audio Wi-Fi Cube IP Camera
HiLook IPC-C340HA-D/W(2.8mm)(W) — 4 MP indoor Wi-Fi fixed cube network camera with two-way audio, microSD storage and Hik-Connect cloud.
- 4 MP (2560 × 1440) high-resolution imaging on 1/3" Progressive Scan CMOS
- 2.8 mm fixed lens — 92° horizontal FOV
- Built-in 2.4 GHz Wi-Fi (802.11 b/g/n, WPA/WPA2-PSK) + PoE / 12 VDC fallback
- Digital WDR for clear images against strong backlight
- Deep-learning human & vehicle classification on motion events
- Built-in microphone & speaker for two-way audio
- 10 m smart-IR night vision (850 nm)
- microSD slot up to 512 GB on-board storage
- Hik-Connect P2P cloud — no port-forwarding needed
Ideal for retail counters, home offices, nurseries and small-business interiors where running cabling is awkward. Works with iVMS-4200, HiLookVision, Hik-Partner-Pro and any ONVIF NVR.
HiLook IPC-C340HA-D/W(W) — 4MP Indoor Wi-Fi Cube Camera with Two-Way Audio
The HiLook IPC-C340HA-D/W(W) is a 4 megapixel indoor Wi-Fi cube network camera designed for fast, cable-light installation in homes, small offices, retail counters and reception areas. The compact plastic housing hides a 1/3" Progressive Scan CMOS sensor delivering 2560 × 1440 imaging, while built-in 2.4 GHz Wi-Fi (802.11 b/g/n) removes the need for a network cable run.
Two-Way Audio Built In
An integrated microphone and speaker make the IPC-C340HA-D/W(W) a true two-way audio camera — ideal for talking to delivery drivers, monitoring family pets or running a small office reception desk. Audio uses G.711 or AAC-LC with environment noise filtering for clearer voice.
Smart Detection & Recording
Deep-learning analytics classify human and vehicle targets, suppressing false motion events from foliage, light changes and pets. Detections can trigger an on-board microSD recording (up to 512 GB), Hik-Connect cloud notification, audible warning, or auto-tracking lite.
Flexible Power & Connectivity
Power with 12 VDC, PoE (IEEE 802.3af Class 3), or just Wi-Fi + 12 VDC PSU. ONVIF and Hikvision SDK support means it pairs cleanly with any HiLook or Hikvision NVR and most third-party VMS platforms.
Key Features
- 4 MP (2560 × 1440) at 25 fps, H.265 / H.264
- 2.8 mm fixed lens, F1.6, M12 mount, 92° horizontal FOV
- 2.4 GHz Wi-Fi 802.11 b/g/n, WPA/WPA2-PSK, up to 150 Mbps
- Smart-IR up to 10 m, 850 nm
- Digital WDR, 4 polygon privacy masks
- Built-in mic + speaker, two-way audio, noise filtering
- Human & vehicle classification (deep learning)
- microSD/SDHC/SDXC up to 512 GB
- PoE 802.3af Class 3 or 12 VDC / 0.38 A
- Hik-Connect cloud, ONVIF, SDK
Specifications
| Camera | |
|---|---|
| Image Sensor | 1/3" Progressive Scan CMOS |
| Max. Resolution | 2560 × 1440 (4 MP) |
| Min. Illumination | Colour: 0.005 Lux @ F1.6, AGC ON; B/W: 0 Lux with IR |
| Shutter Time | 1/3 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan 0°–360°, Tilt 0°–90°, Rotate 0°–360° |
| Lens | |
| Focal Length / FOV | 2.8 mm fixed — H 92° / V 50° / D 110° |
| Aperture | F1.6 |
| Lens Mount | M12 |
| DORI (2.8 mm) | |
| Detect / Observe / Recognise / Identify | 56.0 m / 22.2 m / 11.2 m / 5.6 m |
| Illuminator | |
| Type | IR, smart supplement light |
| Range | Up to 10 m |
| Wavelength | 850 nm |
| Video | |
| Main Stream | 25/30 fps @ 2560 × 1440, 1920 × 1080, 1280 × 720 |
| Compression | H.265 / H.264, Main & Sub stream |
| Bit Rate | Up to 2 Mbps, CBR/VBR |
| Audio | |
| Built-in Mic / Speaker | Yes — both |
| Compression | G.711 / AAC-LC |
| Sampling Rate | 8 kHz / 16 kHz |
| Noise Filtering | Yes |
| Wi-Fi | |
| Protocol | IEEE 802.11 b/g/n |
| Frequency | 2.412 – 2.472 GHz, 20 MHz channel |
| Encryption | WPA-PSK / WPA2-PSK |
| Transfer Rate | Up to 150 Mbps (11n) |
| Wireless Range | Up to 50 m (environment dependent) |
| Network | |
| Protocols | TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, RTSP, RTCP, NTP, UPnP, IGMP, IPv4, UDP, Bonjour, SSL/TLS |
| API | ONVIF, Hikvision SDK |
| Live View | Up to 4 simultaneous channels |
| Client | iVMS-4200, HiLookVision, Hik-Partner-Pro, Hik-Connect |
| Interface | |
| On-Board Storage | microSD / SDHC / SDXC up to 512 GB |
| Ethernet | 1× RJ45 10/100 Mbps |
| Reset Key | Yes |
| Event | |
| Basic Event | Motion detection with human/vehicle target classification, exception |
| Linkage | SD recording, notify centre, snapshot, audible warning, auto-tracking lite |
| General | |
| Power | 12 VDC, 0.38 A, max 4.56 W (Ø 2.0 mm jack); PoE IEEE 802.3af Class 3 |
| Material | Plastic |
| Dimensions | 102.9 × 65.2 × 32.9 mm |
| Weight | ~120 g (camera), ~430 g (boxed) |
| Operating Temp | -10 °C to +45 °C, ≤95 % RH non-condensing |
| Approvals | |
| EMC / RF / Safety | CE-EMC, CE-RED, CE-LVD (EN 62368-1) |
| Environmental | CE-RoHS, WEEE |
What's in the Box
- 1× HiLook IPC-C340HA-D/W(2.8mm)(W) camera with integrated stand
- 1× Mounting template & fixings pack
- 1× Quick start guide
Note: 12 VDC PSU is not supplied — use a CE-approved Ø 2.0 mm 12 V / 1 A adapter, or power via PoE 802.3af Class 3.
