Hikvision DS-KD9633-WBE6 10.1" Android Face Recognition Door Station, Fingerprint & QR
The Hikvision DS-KD9633-WBE6 is a flagship 10.1-inch Android face recognition door station — a combined video intercom and access control terminal for apartment blocks, offices and gated developments.
Dual 2 MP cameras with 120 dB WDR, capacity for 20,000 users and 10,000 faces, and authentication by face, fingerprint, card, PIN, QR code or Bluetooth.
Key Features
- 10.1" colour IPS touchscreen, 1280 × 800, 410 cd/m²
- Android 7.1, 2 GB RAM / 4 GB ROM
- 2 × 2 MP low-light cameras, digital WDR 120 dB, IR to 3 m
- Face, fingerprint, card, PIN, QR code and Bluetooth authentication
- Capacity: 20,000 users, 10,000 faces, 100,000 cards
- 2 relay outputs for lock control · dual RJ-45 · Wi-Fi
- IP65 & IK07 rated, -30°C to +60°C, anodised aluminium frame
Coming soon — new to our range. Contact our trade team for ETA and pre-order allocation.
Hikvision DS-KD9633-WBE6 — 10.1" Android Face Recognition Door Station
Video intercom and access control in one terminal: face, fingerprint, card, PIN, QR and Bluetooth.
Overview
The Hikvision DS-KD9633-WBE6 is the flagship of Hikvision's Ultra series door stations — a 10.1-inch Android touchscreen terminal that combines a full video intercom with enterprise-grade access control. Running Android 7.1 on 2 GB RAM and 4 GB ROM, it handles 20,000 users, 10,000 face records and 100,000 cards, making it suitable for apartment blocks, offices, student accommodation and gated developments rather than single dwellings.
Two 2 MP low-light cameras with digital WDR 120 dB and IR fill to 3 m handle backlit doorways and night use, while the dual-camera arrangement supports the face recognition engine. Residents and staff can be enrolled on face, fingerprint, card, PIN code, QR code or Bluetooth, so one door works for permanent residents, temporary staff and visitors alike.
Built for real doorways: an anodised aluminium frame, ultra-thin profile, IP65 and IK07 protection and a -30°C to +60°C operating range. Two relay outputs drive locks (lock 2 via secure module), with dual RJ-45 and Wi-Fi for connectivity.
Key Features
- 10.1-inch colour IPS touchscreen — 1280 × 800, 410 cd/m²
- Android 7.1 with embedded high-performance processor, 2 GB RAM / 4 GB ROM
- 2 × 2 MP low-illumination cameras, 88° horizontal / 44° vertical FOV
- Digital WDR 120 dB and IR supplement up to 3 m
- Multi-factor authentication — face, fingerprint, card, PIN, QR code, Bluetooth
- Capacity for 20,000 users, 10,000 faces and 100,000 cards
- 2 lock relays (max 30 VDC / 2 A; lock 2 requires the secure module)
- 2 × RJ-45 10/100/1000 Mbps (1 reserved) plus Wi-Fi
- IP65 & IK07 protection, -30°C to +60°C operating range
- Anodised aluminium frame, ultra-thin fuselage — 217 × 159.2 × 26.5 mm
Typical Applications
- Apartment blocks and HMOs — large user capacity with per-resident credentials
- Offices and business parks — staff access plus visitor intercom on one terminal
- Student accommodation and managed residential
- Gated developments needing touch-free entry
Compatible Hikvision Devices
- DS-KDM9633-FKP keypad & fingerprint expansion module
- Hikvision IP indoor stations (DS-KH series) and master stations
- Hik-Connect app and Hikvision access controlHikvision Access Control: The Complete UK Installer Guide software
- MIFARE 13.56 MHz cards, fobs and tags
What's in the Box
- 1 × Hikvision DS-KD9633-WBE6 face recognition door station
- 1 × mounting kit and fixings
- 1 × quick start guide
Detailed Specifications — Hikvision DS-KD9633-WBE6
Full technical specification from the official Hikvision datasheet.
| Identification | |
|---|---|
| SKU | DS-KD9633-WBE6 |
| MPN | DS-KD9633-WBE6 |
| Brand | Hikvision |
| Product Type | Face Recognition Door Station |
| Display & System | |
| Display | 10.1-inch colour IPS touchscreen |
| Resolution | 1280 × 800 |
| Brightness | 410 cd/m² |
| Operating System | Android 7.1 |
| Memory | 2 GB RAM / 4 GB ROM |
| Camera | |
| Cameras | 2 × 2 MP HD, low illumination |
| Field of View | 88° horizontal / 44° vertical |
| WDR | Digital WDR, 120 dB |
| IR Supplement | Up to 3 m |
| Main Stream | 1920 × 1080p, 1280 × 720p |
| Sub Stream | 1280 × 720p, 640 × 480p |
| Authentication & Capacity | |
| Methods | Face, fingerprint, card, PIN code, QR code, Bluetooth |
| User Capacity | 20,000 |
| Face Capacity | 10,000 |
| Card Capacity | 100,000 |
| Interfaces | |
| Network | 2 × RJ-45 10/100/1000 Mbps (1 reserved) |
| Wireless | Wi-Fi |
| Lock Control | 2 relays, max 30 VDC / 2 A (lock 2 requires secure module) |
| Power & Environment | |
| Power Supply | 12 VDC, 2 A |
| Power Consumption | 18 W |
| Operating Temperature | -30°C to +60°C |
| Operating Humidity | 10% to 90% |
| Protection | IP65, IK07 |
| Mechanical | |
| Dimensions | 217 × 159.2 × 26.5 mm (H × W × D) |
| Construction | Anodised aluminium frame, ultra-thin fuselage |
Frequently Asked Questions
What is the Hikvision DS-KD9633-WBE6?
A 10.1-inch Android face recognition door station that combines video intercom and access control in one outdoor terminal.
How many users does it support?
20,000 users, 10,000 face records and 100,000 cards — suited to apartment blocks and commercial sites rather than single homes.
What authentication methods are supported?
Face, fingerprint, card, PIN code, QR code and Bluetooth.
Does fingerprint need an extra module?
The DS-KDM9633-FKP keypad and fingerprint module extends the KD9633 with a 15-button keypad and fingerprint reader for 5,000 fingerprints.
Is it suitable for outdoor use?
Yes — IP65 and IK07 rated with a -30°C to +60°C operating range.
Is it available yet?
This line is new to our range and coming soon. Contact Netview CCTV Leicester on 0116 3800 838 for ETA and pre-order allocation.
