Hikvision DS-52EX01HI-4K, 4K HDMI & USB Extender upto 120m over Cat5/Cat6
Hikvision DS-52EX01HI-4K, 4K HDMI & USB Extender
View & Control any DVR or NVR up to 120m away.
The HDMI Extender, when paired with NVRs/DVRs, allows you to transmit 4K resolution video through Ethernet cables for the distance of up to 120 meters. It also supports remote control of video recorders via USB controller
- Up to 4K resolution and stable 120 m long-distance transmission
- Compatible with major video recorders in the market
- Plug-and-play, synchronous transmission of video and audio
- No latency in video image, extraordinary user experience
- Video and Audio
- HDMI Output
Receiver: 1-ch
Resolution: 4K (3840 × 2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080p/60 Hz, 1080 × 720/60 Hz
- HDMI Input
Transmitter: 1-ch
Resolution: 4K (3840 × 2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080p/60 Hz, 1080 × 720/60 Hz
- Auxiliary Interface
- Serial Interface
Transmitter: 1, console interface
Receiver: 1, console interface
- USB Interface
Transmitter: 1
Receiver: 1
- General
- Power Supply12 VDC, 1 A
- Consumption
Transmitter: ≤ 5 W
Receiver: ≤ 5 W
- Working Temperature-10 °C to 45 °C (14 °F to 113 °F)
- Working Humidity10% to 90%
- Dimension (W × D × H)
Transmitter: 96 mm × 60 mm × 26 mm ( 3.76"× 2.36\" × 1.02\")
Receiver: 96 mm × 60 mm × 26 mm ( 3.76 × 2.36\" × 1.02\")"
- ≤ 1 kg
- Others
- Power Indicator
Transmitter: 1 power indicator
Receiver: 1 power indicator
- Video Transmission
- Transmission Distance
Resolution for 120 m transmission distance (with Cat6 Ethernet cable):
4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1080 × 720/60 Hz
Resolution for 100 m transmission distance (with Cat5e Ethernet cable):
4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1080 × 720/60 Hz
Resolution for 60 m transmission distance (with Cat6/Cat5e Ethernet cable):
4K (3840 × 2160)/60 Hz, 2K (2560 × 1440)/60 Hz
- Transmission Interface1, RJ45
