Hikvision DS-3E0106HP-E 4-Port Hi PoE Switch Long Range PoE + 2 Uplinks
Hikvision DS-3E0106HP-E 4-Port PoE Switch
DS-3E0106HP-E switches are layer 2 100 Mbps long-range PoE switches, providing 1 × 10/100 Mbps Hi-PoE port, 3 × 10/100 Mbps PoE ports, and 2 × 10/100 Mbps RJ45 ports. The switches provide advanced Hi-PoE/PoE technology and support extend mode with long-range access up to 250 m. The prior and stable transmission of the important surveillance area videos can also be guaranteed when connected to the high priority ports. Meanwhile, the 2 × 10/100 Mbps RJ45 uplink ports guarantee applications of multiple network solutions.
- 1 × Hi-PoE port, 3 × PoE ports, and 2 × Uplink ports.
- When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
- Up to 300m Long Range PoE Transmission. The distance between IPC's and switch can reach maximum 300meters.
- 4/8-Core Adaptive Power Supply with Less Power Loss. 8-core power supply reduces the power loss on cables.
- 6KV Surge Protection to Improve Reliability in Harsh Environment.
- The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.
- Design for Video Transmission. VIP port ensures important data transmission when network congestion occurs.

Network Parameters
- Port Number 1 × 10/100 Mbps Hi-PoE port, 3 × 10/100 Mbps PoE ports, and 2 × 10/100 Mbps RJ45 ports
- Port Type RJ45 port, full duplex, MDI/MDI-X adaptive
- Working Mode Standard mode (default); Extend mode
- Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Forwarding Mode Store-and-forward switching
- Ports For Long-Distance Transmission Ports 1 to 4
- MAC Address Table 2 K
- Internal Cache 768 Kbits
- Switching Capacity 1.2 Gbps
- Packet Forwarding Rate 0.893 Mpps
- High Priority Ports Ports 1 to 2
PoE Power Supply
- PoE Standard
Port 1: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Ports 2 to 4: IEEE 802.3af, IEEE 802.3at
- PoE Power Pin
End-span: 1/2(-), 3/6(+)
Mid-span: 4/5(+), 7/8(-)
8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
- PoE Port Ports 1 to 4
- Max. Port Power
Port 1: 60 W
Ports 2 to 4: 30W
- PoE Power Budget 6 W
Dialing Function
- Long Range Ports 1 to 4: up to 300m; and the speed rate of the port is 10Mbps.
General
- Dimension (W × H × D)145 mm × 25.6 mm × 68.45 mm (5.7” × 1.0” × 2.7”)
- Storage Temperature -40 °C to 85 °C (-40 °F to 185 °F)
- Storage Humidity 5% to 95% (no condensation)
- Gross Weigh t0.77 kg (1.70 lb)
- Net Weight 0.24 kg (0.53 lb)
- Power Consumption In Idle 5 W
- Shell Metal material, fan-free design
- Operating Temperatur e-10 °C to 55 °C (14 °F to 131 °F)
- Operating Humidity 5% to 95% (no condensation)
- Power Supply 48 VDC, 1.35 A
- Max. Power Consumption 65 W
Approval
- EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
- SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
- ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
