Ajax 60815 ManualCallPoint (Red) Jeweller - EN54 Fire Alarm Call Point
Ajax 60815 ManualCallPoint (Red) Jeweller - EN54Ajax EN54 Fire Protection FireAjax Fire Alarm vs Intruder Alarm: UK Compliance for Combined Systems Alarm Call Point | netviewcctv.co.uk
ManualCallPoint (Red) Jeweller is a fast and straightforward way for anyone to activate the fireAjax Fire Alarm vs Intruder Alarm: UK Compliance for Combined Systems alarm. Pressing the button triggers the built-in sirens of all fireAjax Fire Alarm vs Intruder Alarm: UK Compliance for Combined Systems detectors in the system and informs the users. Meanwhile, the central monitoring station (CMS) receives the alarm and calls emergency services. All the data is instantly available in Ajax apps: which device was triggered, when, and where. In a life-endangering situation, Ajax innovative features follow an alarm in seconds: automation scenarios de-energize the facility, turn the emergency lights, and unlock the exits.
- Wireless EN 54-11 & EN 54-25 certified resettable manual call point for fireAjax Fire Alarm vs Intruder Alarm: UK Compliance for Combined Systems alarm activation
- Default FireAjax Fire Alarm vs Intruder Alarm: UK Compliance for Combined Systems Alarm mode – triggers all fireAjax Fire Alarm vs Intruder Alarm: UK Compliance for Combined Systems detector sirens and notifies monitoring station instantly
- Resettable frangible element – reset with bundled key, ready to reuse immediately
- Up to 1,700 m wireless range with encrypted Jeweller radio protocol
- Pre-installed CR123A batteries – up to 7 years battery life
- Programmable automation scenarios – de-energise facility, unlock exits, activate emergency lighting
- Tamper-protected with transparent protective lid to prevent accidental activation
- 5-minute SmartBracket wall installation at recommended 1.4 m height
Ajax Systems Product Information Page : Ajax EN54 ManualCallPoint (Red) Product Information
Ajax Systems Product Technical Specifications : Ajax EN54 ManualCallPoint (Red) Technical Specifications
Ajax Fire HubAjax Fire Hub Jeweller EN54 — UK Installer Guide Jeweller — UK Installer Guide
Spec, sizing, commissioning and the full Ajax Jeweller fireAjax Fire Alarm vs Intruder Alarm: UK Compliance for Combined Systems ecosystem (Hub, ReX, FireProtect, manual call points) for UK BS 5839-1 / EN54Ajax EN54 Fire Protection installs.
Ajax FireAjax Fire Alarm vs Intruder Alarm: UK Compliance for Combined Systems vs Intruder — UK Compliance Guide
How to specify combined Ajax fireAjax Fire Alarm vs Intruder Alarm: UK Compliance for Combined Systems and intruder systems for UK BS 5839-1, PD 6662 and EN 50131 Grade 2 — which panel does what, and which devices belong on each side.
Ajax ManualCallPoint (Red) Jeweller – Wireless Manual Fire Alarm Call Point
The Ajax ManualCallPoint (Red) Jeweller is a wireless addressable resettable button specifically designed for manual fire alarm activation. Certified to EN 54-11 and EN 54-25 standards, the red variant defaults to Fire Alarm mode – pressing it immediately triggers the built-in sirens of all connected fire detectors, sends an alarm to the monitoring station, and activates any configured automation scenarios.
Instant Fire Alarm Activation
In a fire emergency, every second counts. Lifting the transparent protective lid and pressing the frangible element activates the alarm instantly. All connected Ajax fire detectors sound their built-in sirens simultaneously, while users and the monitoring station receive immediate notifications via the Ajax app. The alarm remains active until the button is reset using the bundled special key – a deliberate design choice that prevents premature silencing.
Programmable Automation Scenarios
Beyond sounding alarms, the ManualCallPoint can trigger up to 64 automation scenarios configured through the EN54 Fire Hub Jeweller. A single press can de-energise the building via WallSwitch, unlock emergency exits via Relay, activate LED evacuation signage via I/O Module, and switch on emergency lighting – all within seconds of activation.
Reliable Mechanism Built for Emergencies
The button mechanism is deliberately simplified to a few solid parts, minimising any risk of mechanical failure during a critical moment. Designed for over 500 activations throughout its lifecycle, with Ajax testing 100% of production during manufacturing. The device is powered by pre-installed CR123A batteries providing up to 7 years of operation.
Supervised IoT Device
Unlike conventional manual call points that sit untested between fire drills, the ManualCallPoint exchanges data with the CIE every minute via the encrypted Jeweller protocol. If the button develops a fault, the system notifies the security company and users immediately – specifying which device on which premises has the issue. No periodic testing by triggering is required.
What's in the Box
ManualCallPoint (Red) Jeweller, SmartBracket mounting panel, 2 × CR123A batteries (pre-installed), special tool (key), transparent protective lid, installation kit, and quick start guide.
